Working voltage | DC 9v-16v |
Antenna working voltage | DC 11.5v-12.5v |
Operating temperature | -30 ℃ ~ 70 ℃ |
Storage temperature | - 40 ℃ ~ + 80 ℃ |
Decoding chip | BCM73625 |
Demodulation chip | Parrot Octopus 3 |
Note: Specific specifications are subject to the actual model of the manufacturer
Signal reception | supports 4-antenna hierarchical reception |
Function | supports processing DTMB signals; It supports high-speed movement, and the designed theoretical moving speed can exceed 200 km / h |
Audio and video output | support HDML YPbPr CVBS |
Bandwidth | support 6m, 7m and 8M |
Frequency and range | 170mhz-860mhz |
HD video decoding | support MPEG-1 / 2 / 4; H.264; AVS,AVS+,VC-1,VP8 |
Audio processing | support MPEG-1; MPEG-2(Layer I/II) ; MP3 ; AC-3 (Dolby Digital): E-AC-3 (Dolby Digital plus) |
Module communication protocol | support module CAN bus protocol,IC bus protocol |
Note: Specific specifications are subject to the actual model of the manufacturer
